Holden Trailblazer Owner Manual (Australia-Localizing-Australia-12333016) -
2019 - crc - 3/2/18
Vehicle Care 245
Low Beam
1. Remove the protective cover.
2. Unplug the connector
from bulb.
3. Press the spring clip and
disengage the bulb.
4. Remove the bulb from the
reflector housing.
5. When fitting a new bulb,
engage the lugs in the
recesses on the reflector and
press the bulb into position.
6. Plug the connector onto bulb.
7. Place the protective cover in
the right position and close it.
Headlamp Aim
Caution
If the headlamps need to be
re-aimed, it is recommended that
the vehicle is taken to a Holden
dealer.
Front Turn Signal Lamps
1. Rotate bulb holder
anticlockwise and disengage.
To Next Page
