9
9-33
Battery capacity label
2C_BatteryCapacityLabel_AGM
• The actual battery label in the vehicle
may differ from the illustration.
1. AGM70L-DIN : The HYUNDAI model
name of battery
2. 12V : The nominal voltage
3. 70Ah (20HR) : The nominal capacity (in
Ampere hours)
4. RC 120min : The nominal reserve
capacity (in min.)
5. CCA 5760A (SAE/EN) : The cold-test
current in amperes
For vehicles with power liftgate, note that
the power liftgate needs to be reset after
the battery has been replaced. For more
information, refer to the “Power Liftgate”
section in chapter 5.
Battery recharging
By battery charger
Your vehicle has a maintenance free,
calcium based battery.
• If the battery becomes discharged in a
short time (because, for example, the
headlights or interior lights were left on
while the vehicle was not in use),
recharge it by slow charging (trickle) for
10 hours.
• If the battery gradually discharges
because of high electric load while the
vehicle is being used, recharge it at
20-30 A for two hours
Always follow these instructions when
recharging your vehicle’s battery to avoid
the risk of SERIOUS INJURY or DEATH
from explosions or acid burns:
• Before performing maintenance or
recharging the battery, turn off all
accessories and press the Engine
Start/Stop button to the OFF position.
• Keep all flames, sparks, or smoking
materials away from the battery.
• Always work outdoors or in an area with
plenty of ventilation.
• Wear eye protection when checking the
battery during charging.
• The battery must be removed from the
vehicle and placed in a well ventilated
area.
• Watch the battery during charging, and
stop or reduce the charging rate if the
battery cells begin boiling violently.
• The negative battery cable must be
removed first and installed last when
the battery is disconnected. Disconnect
the battery charger in the following
order:
Hyundai_SX2_en_US.book Page 33
