AquaLink
®
Touch™ Owner's Manual
Section 10. System Setup
10.1 System Setup Screen
The SYSTEM SETUP menu screen allows you to
configure pool/spa equipment, devices and AquaLink
Touch features. This section of the manual provides
instructions to set up most of these equipment.
For the following equipment, see their corresponding
section.
See Section 2, "Overview of the AquaLink Touch
Controller".
See Section 11, "Heat Pump Setup".
See Section 12, "Variable Speed Pump Setup".
See Section 14, "ChemLink™ Setup".
NOTE Some equipment may not be part of your
system. Please check with your installer.
10.1.1 To Access System Setup
MENU > SYSTEM SETUP
From the MENU screen, touch the SYSTEM SETUP
button to display the SYSTEM SETUP menu.
H
ome Menu OneTouch Help Back Status
Photos
Power
Thu January 1, 2009 3:03 PM
System Setup
Freeze
Protection
VSP
Settings
ESP
Link
OneTouch
Setup
Device
Runtime
Label
Aux
Spa
Remotes
Maintain
Temp
Color
Lights
Setup
RS Interlink
Disable
Sprinkler
Dimmers
Use the ARROW buttons to display additional
equipment.
Ho
m
e
Menu OneTouch Help Back Status
Photos
Power
System Setup
Dusk
Setup
Heat
Pump
PLockOut
Enabled
Air Temp
Enabled
HP Priority
N/A
DST
Enabled
Temp
Calibrate
Slr Priority
Disabled
All Off
Time
Product
Info
Degrees
Fº
Assign
JVAs
Thu January 1, 2009 3:03 PM
Use the ARROW buttons to display additional
equipment.
H
om
e
Menu OneTouch Help Back Status
Photos
Power
System Setup
In-Floor
Disable
Clear
Memory
Cancel
Delay
Chemlink
Thu January 1, 2009 3:03 PM
10.2 Label Auxiliary Functions
The LABEL AUX menu allows custom naming of
auxiliary equipment. For example, you can set the
display to read Pool Light JL instead of AUX 4.
10.2.1 To Set Up Label Auxiliary
MENU > SYSTEM SETUP > LABEL AUX
From the SYSTEM SETUP screen, touch the LABEL
AUX button to display the LABEL AUXILIARIES
screen.
Highlight the CIRCUIT and touch your choice - general,
lights, water features, or custom.
Label Auxiliaries
Circuit Circuit Name Freeze
Aux 1 Cleaner Yes
Aux 2 Low Speed Yes
Aux 3 Spillover Yes
Aux 4 Pool Light JL No
Aux 5 Spa Light JL No
Aux 6 Fountain Yes
Aux 7 Blower No
Aux 8 None Yes
Freeze
Protect
Page
Down
Page
Up
Save
Water
Feature
Lights
Custom
General
Hom
e
Menu OneTouch Help Back Status
Photos
Power
Thu January 1, 2009 3:03 PM
NOTE Please be aware that if the label NOT USED
from the GENERAL LABEL menu is used on an
AUX relay, the relay will not engage.
