Section 12. Variable Speed Pump
Setup
NOTE This equipment may not be part of your system.
Please check with your installer.
A VARIABLE SPEED PUMP can be programmed to
run at any one of its eight (8) speeds.
Power to the variable speed pump is switched on/off
by a relay, so to program the pump you need to set a
program time for the relay, and for any speeds that you
wish to run during the pump's on cycle.
In the example shown below the variable speed pump
is used for pool filtration, so it will be powered from
the FILTER PUMP relay. Therefore, to program the
variable speed pump you must first set a program time
for the FILTER PUMP relay, then you need to program
the desired pump speeds to turn on/off during the
FILTER PUMP cycle.
If you do not program any speeds to run during the
filtration cycle, then by default the variable speed pump
will run at the POOL speed setting during its filtration
cycle.
Example:
1. The total length of the fi ltration cycle is to be from
8am to 5pm. So program the FILTER PUMP to turn
on at 8am and to turn off at 5pm.
2. To run the variable speed pump at the SPEED3
setting from 8am to 1pm, select VSP SPD1 PGM,
then select SPEED3, program it to turn on at 8am
and off at 1pm.
3. To run the variable speed pump at the SPEED4
setting from 1pm to 5pm, select VSP SPD1 PGM,
then select SPEED4, program it to turn on at 1pm
and off at 5pm.
ON OFF DESCRIPTION
FILTER PUMP 8AM 5PM Total duration of
filtration cycle
SPEED3 8AM 1PM Pump runs at the
SPEED3 setting
SPEED4 1PM 5PM Pump runs at the
SPEED4 setting
The VAR SPEED PUMP menu is used to select the
variable speed pump type (Jandy ePump™, Pentair
®
IntelliFlo
®
VF, Pentair IntelliFlo VS, or Pentair
IntelliPro VS) and to select the various pump settings.
To interface the IntelliPro VS, select IntelliFlo VS.
12.1 To Select the Pump/Model
MENU > SYSTEM SETUP > VSP SETUP
From the SYSTEM SETUP screen, touch the VSP
SETUP button to display the VSP SETUP screen.
From the VSP SETUP screen, touch the PUMP/
MODEL button to display the SELECT VSP screen.
Touching the RESTORE SPD DEFAULTS button will
set the pump speeds, prime speeds and prime duration
to their factory default settings.
H
ome Menu OneTouch Help Back Status
Photos
Power
Speed
Setup
Pump/Model Application Min Max Speed Duration
1 Jandy ePump Filtration 400 RPM 3450 RPM 2500 :05
2 Pentair VS Aux Pump 900 RPM 3000 RPM 2500 :05
3 Pentair VF Not Installed N/A N/A N/A N/A N/A N/A
4 VSP AC Not Installed N/A N/A N/A N/A N/A N/A
VSP Setup
Save
Restore Spd
Defaults
Thu January 1, 2009 3:03 PM
Priming Priming
In the PUMP MODEL list, select the variable speed
pump type and touch the SELECT button to save it.
Ho
m
e
Me
n
u
O
neTouc
h
He
l
p B
ack
S
tatus P
hotos
Powe
r
Select VSP
Select
Pump Model
Jandy ePump
Pentair VS
Pentair VF
VSP AC
Thu January 1, 2009 3:03 PM
