AquaLink
®
Touch™ Owner's Manual
14.4 Manual Feed Activation
14.4.1 To Perform an ORP Manual Feed
From the CHEMLINK setup screen, highlight the
ORP MANUAL FEED entry. A CONFIRM dialog box
will appear, touch the YES button to proceed with the
manual ORP feed.
ChemLink
H
o
m
e
Menu OneTouch Help Back Status
Photos
Power
Thu January 1, 2009 3:03 PM
ORP 650
pH 7.5
ORP/pH Setup
ORP Manual Feed
pH Manual Feed
Level Switch
Select
ChemLink 1
14.4.2 To Perform a pH Manual Feed
From the CHEMLINK setup screen, highlight the pH
MANUAL FEED entry. A CONFIRM dialog box will
appear. Touch the YES button to proceed with the
manual pH feed.
ChemLink
H
o
m
e
Menu OneTouch Help Back Status
Photos
Power
Thu January 1, 2009 3:03 PM
ORP 650
pH 7.5
ORP/pH Setup
ORP Manual Feed
pH Manual Feed
Level Switch
Select
ChemLink 1
14.4.3 To Enable the ChemLink™ Feeder
Tank Level Switch
This feature allows the use of an external, tank-mounted
level switch to indicate when a liquid tank is empty to
prevent the dry feeding of a peristaltic pump. These
switches are an after-market product and not available
through Jandy. There are only provisions for one (1)
switch. The switch must be normally closed (NC).
From the CHEMLINK setup screen, highlight the
LEVEL SWITCH entry. An ‘X’ on the display indicates
the Level Switch is enabled. Touch the LEVEL
SWITCH again to disable it.
ChemLink
Ho
m
e
Menu OneTouch Help Back Status
Photos
Power
Thu January 1, 2009 3:03 PM
ORP 650
pH 7.5
ORP/pH Setup
ORP Manual Feed
pH Manual Feed
Level Switch X
Select
ChemLink 1
