1 . T ransmitter Controls
1
.
1 Control Identification and Location
A
ntenna
LCD Dis
p
la
y
(
Do Not Press
)
A
ux 2 Knob
Car
r
y
in
g
Handle
Snap Roll/
T imer/
T
rainer Switch
A
ux 3 Knob
P . Mix Switch/Aux 2
Gear Switch
Rudder Dual Rate Switch
Elevator Dual Rate Switch
A
ileron Dual Rate Switch
Fla
p
/Mixin
g
Switch
Fla
p
Knob
Neck Strap Eyelet
Throttle/Rudde
r
Stic
k
Elevator
T
rim
Elevator/Aileron Stick
Throttle T rim
Rudder
T
rim
A
ileron
T
rim
Power Switch
In
p
ut Ke
y
s
Channel Assi
g
nment/Throttle
A
L T Throttle AL T
Channel # TX Function Airplane Function
1 Thro Throttle Channel
2 Aile Aileron Channel
3 Elev Elevator Channel
4 Rudd Rudder Channel
5 Gear Gear Channel
6 Flap Auxillar y 1 Channel (Flap)
7 SPOI Auxillar y 2 Channel (Spoiler)
8 Aux 3 Auxilla
r
y
3 Channel
The Throttle AL T function makes the throttle stick trim active only
when the throttle stick is at less than half throttle. This gives easy
,
accurate idle adjustments without af fecting the high throttle
position.
