1 . T ransmitter Controls
1
.
1 Control Identification and Location
A
ntenna
LCD Dis
p
la
y
(
Do Not Press
)
Hoverin
g
Pitch Knob
Car
r
y
in
g
Handle
T imer/
T
rainer Switch
Hoverin
g
Throttle Knob
(
Aux2
)
Throttle Hold Switch
Fli
g
ht Modes
(
Aux 3
)
Rudder Dual Rate Switch
Elevator Dual Rate Switch
A
ileron Dual Rate Switch
Pitch T rim Knob
Gear/Inve
r
ted Switch
Neck Strap Eyelet
Throttle (collective)/
Rudder Stick
Elevator
T
rim
Elevator/Aileron Stick
Throttle T rim
Rudder
T
rim
A
ileron
T
rim
Power Switch
In
p
ut Ke
y
s
Channel Assi
g
nment/Throttle
A
L T Throttle AL T
Channel # TX Function Airplane Function
1 Thro Throttle Channel
2 Aile Aileron Channel
3 Elev Elevator Channel
4 Rudd Rudder Channel
5 Gear Gear Channel
6 Aux 1 Auxillary 1 Channel (Pitch)
7 Aux 2 Auxillar y 2 Channel (Gyro Sensitivity)
8 Aux 3 Auxilla
r
y
3 Channel
The Throttle AL T function makes the throttle stick trim active only
when the throttle stick is at less than half throttle. This gives easy
,
accurate idle adjustments without af fecting the high throttle
position.
HELI 58
