2 . 2 Receiver
NER-64 9S
(
PCM S
y
stems
)
NER-54 9
(
FM S
y
stems
)
• This is a high per for mance PCM-FM single conversion receiver
with 1 0 KHz super narrow band ABC&W circuitr y .
• The latest “S” type Central Processing Unit (CPU) is used in the
PCM receiver. The new NER-64 9S of fers the highest resolution
available in any receiver .
• A narrow band ceramic filter for high signal selectivity also
assists in rejecting cross modulation from other common radio
frequencies (e.g., R/C transmitters, local paging systems). It has
the highest degree of resistance to electro-mechanical “noise” to
improve signal reception.
• This receiver features Direct Ser vo Control (DSC) per mits
control of sur faces without radio frequency output.
• The receiver has low current consumption.
• 3-
p
oint
g
old
p
lated connectors allow increased conductivit
y
.
• The NER-54 9 is a high per for mance FM single conversion
receiver with 1 0 KHz super-narrow band ABC&W circuitr y .
• A narrow band ceramic filter for high signal selectivity assists
in rejecting cross modulations from other common radio
frequencies (e.g., R/C transmitters, local paging systems).
• This receiver features Direct Ser vo Control (DSC) for control of
sur faces without radio frequency output.
• The receiver has low current consumption.
• 3-
p
oint
g
old
p
lated connectors allow increased conductivit
y
.
2 . 3 Ser vo Features
50 7 Servo 53 1 Servo
• A zero deadband amplifier insures accurate neutral centering.
• The 5 0 7 has low current drain.
• An indirect drive feedback potentiometer gives additional
protection from vibration.
• Redesigned features include SMT (Sur face Mount T echnology)
circuitr y .
• The 5 0 7 features a 3-pole ferrite cored motor .
51 7 Servo
• The 5 1 7 features a ball bearing output shaft for precise
movement of your aircraft’ s control outputs.
• A zero deadband amplifier insures accurate neutral centering.
• The 5 1 7 has low current drain.
• An indirect drive feedback potentiometer gives additional
protection from vibration.
• Includes SMT (Sur face Mount T echnology) circuitry .
• The 5 1 7 features a 3-pole ferrite cored motor .
• The 5 3 1 features a ball bearing output shaft for precise
movement of your aircraft’ s control outputs.
• A zero deadband high per for mance amplifier insures accurate
neutral centering and high tor que (5 1oz./in.) with a speed of
.23 sec/6 0°.
• The 5 3 1 has low current drain.
• An indirect drive feedback potentiometer gives additional
protection from vibration.
• Includes SMT (Sur face Mount Technology) Circuitr y .
• The
5
3
1 features a 3-
p
ole ferrite cored moto
r
.
XP
8
10 3 9
