Juniper SRX110 H2 User Manual

Table 11: SRX110 Services Gateway Front Panel Components LEDs
UsageDescriptionComponent
The Alarm LED can be used
to gather information on
critical, major, or minor
alarms or to determine if the
device is functioning
normally.
The Alarm LED has the following indicator colors:
•
Solid red indicates a critical alarm.
•
Solid amber indicates a major alarm.
•
Green indicates that the device is functioning
normally with no alarms.
•
Off indicates that the device is not powered on.
NOTE: When the system is up and running, if
the Alarm LED is off, it indicates that no alarms
are present on the device.
Alarm LED
The Status LED can be used
to determine whether the
device is starting up, is
functioning normally, or has
failed.
The Status LED has the following indicator colors:
•
Solid green indicates that the device is
functioning normally.
•
Solid amber indicates that the device is starting
up.
•
Solid red indicates that the device has failed.
•
Off indicates that the device is not powered on.
Status LED
The Power LED can be used
to determine if the device is
receiving power.
The Power LED has the following indicator colors:
•
Solid green indicates that the device is
functioning normally.
•
Solid amber indicates that the Power button
has been pressed and quickly released. The
device is gracefully shutting down.
•
Solid red indicates that there is a problem with
the power supply.
•
Off indicates that the device is not receiving
power.
Power LED
The 3G LED can be used to
determine if the 3G USB
modem is plugged in.
NOTE: The 3G LED will be
functional only if you reboot
the services gateway after
plugging in the modem.
The 3G LED has the following indicator colors:
•
Solid green indicates that the 3G USB modem
is functioning normally or connected to network.
•
Solid red indicates that the 3G USB modem is
not registered with network.
•
Solid amber indicates that the 3G USB modem
is registered with network.
•
Off indicates that the 3G USB modem is not
detected.
3G LED
Copyright © 2015, Juniper Networks, Inc.20
SRX110 Services Gateway Hardware Guide for H2 Model Numbers
