If you are mounting the device in a rack with other equipment, or if you are placing it
on the desktop near other equipment, ensure that the exhaust from other equipment
does not blow into the intake vents of the chassis.
Table 19 on page 35 provides clearance requirements for maintaining optimum airflow
and for facilitating maintenance of the device.
Table 19: Clearance Requirements for the Services Gateway
Requirement for Clearance
Recommended
ClearanceLocation
Space for service personnel to
remove and install hardware
components
2.5 in. (6.35 cm)Front of the chassis
Space for service personnel to
remove and install hardware
components
2.5 in. (6.35 cm)Rear of the chassis
Space for cable management and
organization
2.5 in. (6.35 cm)Between the front-mounting
flange and rack or cabinet edge
Space for the cooling system to
function properly and to maintain
unrestricted airflow around the
chassis
2.5 in. (6.35 cm)Between the side of the chassis
and any non-heat-producing
surface such as a wall or
cabinet side
Space for the cooling system to
function properly and to maintain
unrestricted airflow around the
chassis
2.5 in. (6.35 cm)Between the side of the chassis
and devices that have fans or
blowers
Related
Documentation
• General Site Guidelines for Installing the SRX110 Services Gateway on page 30
• SRX110 Services Gateway Cabinet Requirements on page 32
• SRX110 Services Gateway Rack Requirements on page 33
