Model 6517B Electrometer Reference Manual Section 14: SCPI command reference
6517B-901-01 Rev. C / August 2015 14-13
:SENSe command summary
Command Description Default parameter SCPI
[:SENSe[1]]
:FUNCtion <name>
Select measurement function:
‘VOLTage[:DC]’, 'CURRent[:DC]’,
‘RESistance’, ‘CHARge’
‘VOLT:DC’

:FUNCtion?
Query function

:DATA
Path to return readings:

[:LATest]?
Return the last instrument reading

:FRESh?
Query fresh readings

:VOLTage[:DC]
Path to configure volts:

:APERture <n>
Set integration rate in seconds (166.67e-6
to 200e-3)
(Note 1)

:AUTO <b>
Enable or disable auto aperture OFF
:AUTO ONCE
Enable and then disable auto aperture
:AUTO?
Query auto aperture
:APERture?
Query aperture (integration rate)

:NPLCycles <n>
Set integration rate (line cycles; 0.01 to
10)
1

:AUTO <b>
Enable or disable auto NPLC OFF
:AUTO ONCE
Enable and then disable auto NPLC
:AUTO?
Query auto line cycle integration
:NPLCycles?
Query line cycle integration rate

:RANGe
Path to configure measurement range: 200

[:UPPer] <n>
Select range (0 to 210)

[:UPPer]?
Query range

:AUTO <b>
Enable or disable auto range (Note 4)

:AUTO ONCE
Set range based on present input signal

:ULIMit <n>
Set upper limit for auto range (0 to 210) 200
:ULIMit?
Query upper limit
:LLIMit <n>
Set lower limit for auto range (0 to 210) 2
:LLIMit?
Query lower limit
:AUTO?
Query auto range

:REFerence <n>
Specify reference (-210 to +210) 0

:STATe <b>
Enable or disable reference OFF

:STATe?
Query state of reference (0 or 1)

:ACQuire
Use input signal as reference

:REFerence?
Query reference value

:DIGits <n>
Specify measurement resolution (4 to 7) 6
:AUTO <b>
Enable or disable auto resolution
:AUTO ONCE
Enable and then disable auto resolution
