Section 14: SCPI command reference Model 6517B Electrometer Reference Manual
14-76 6517B-901-01 Rev. C / August 2015
:TYPE <name>
This command is used to select the filter type for volts, amps, ohms, and volts.
Usage
[:SENSe[1]]:VOLTage[:DC]:AVERage:TYPE <name>
[:SENSe[1]]:CURRent[:DC]:AVERage:TYPE <name>
[:SENSe[1]:RESistance:AVERage:TYPE <name>
[:SENSe[1]]:CHARge:AVERage:TYPE <name>
:TYPE?
<name>
ï‚· NONE: No digital filter selected
ï‚· SCALar: Select scalar filter
ï‚· ADVanced: Select advanced filter
Details
Description This command is used to select the digital filter type. The SCALar filter is a simple
averaging type filter. The ADVanced filter is similar except that it incorporates a noise window to allow
faster response time to large signal step changes. The :NTOLerance command is used to set the
window for the ADVanced filter.
The number of readings that are averaged by the filter is set with the :COUNt command, and the
:TCONtrol command is used to select the filter mode (moving or repeating). The [:STATe]
command is used to enable or disable the filter.
Setting TYPE to NONE with MEDian:STATe set to OFF sets AVER:STATe to OFF.
Also see
None
:TCONtrol <name>
This command is used to select the filter mode for volts, amps, ohms, and coulombs.
Usage
[:SENSe[1]]:VOLTage[:DC]:AVERage:TCONtrol <name>
[:SENSe[1]]:CURRent[:DC]:AVERage:TCONtrol <name>
[:SENSe[1]:RESistance:AVERage:TCONtrol <name>
[:SENSe[1]]:CHARge:AVERage:TCONtrol <name>
:TCONtrol?
<name>
ï‚· REPeat: Select repeating filter mode
ï‚· MOVing: lect moving filter mode
Details
These commands are used to select the filter mode (REPeat or MOVing) for the specified function
(see Digital filters (on page 9-2) for more information).
MOV during scan or test sequence generates a "Settings Conflict Error." TCON is set to REPeat during
a scan or test sequence if filter is ON and the appropriate function is encountered.
Also see
None
