(b) Warning when leaving the operator's seat
(c) Warning for operation, inspection and maintenance
(2) Warning no passengers
(3) Warning danger of falling objects
(4) Caution for blast jobsite
(5) Warning for quick coupler system
(6) Caution for overloading machine
(7) Lifting capacity diagram
(8) Combined safety information label
(a) Warning prohibited to enter in swing radius
(b) Caution when standing in operator cab
(c) Control levers operational function diagram
(9) Warning when swinging and travelling in reverse
(10) Caution when stowing front window
(11) Battery main switch
(12) Caution for handling battery
(13) Caution for handling cable
CONTENTS OF SAFETY LABELS
(1) Combined safety information label
(22B-00-21220)
• Warnings for operation, inspection and maintenance.
(14) Caution for high temperature coolant and hydraul-
ic oil
(15) Caution for adjusting track tension
(16) Caution against falling
(17) Caution stop rotation during inspection and main-
tenance
(18) Caution against falling
(19) Danger do not enter within swing range
(20) Caution for handling accumulator and gas spring
(21) Caution for work equipment
(22) Warning for handling ROPS
(23) Caution do not start by short-circuiting
(24) Caution for handling DEF
(25) Caution for handling DEF
(26) Caution for high-temperature fuel
(27) Emergency escape
(28) Lock front window
• Improper operation and maintenance can cause serious in-
jury or death.
• Read the manual and labels before operation and mainte-
nance.
Follow instructions and warnings in manual and in labels on
machine.
Detailed explanations of the content of each label are as fol-
lows:
(a) Warning against high-voltage cable
• An electrocution hazard if the machine is brought too near
to electric power lines.
• Keep a safe distance from electric power lines.
To Next Page
