2500 mm arm specification
Max. vertical wall digging depth
Max. digging depth of cut for 2440
mm level
Max. digging reach at ground level
EXPLANATION OF LIFT CAPACITY CHART
The excavator used in handling operations must conform with current local regulations and be equip-
ped with safety valves and an overload alarm in compliance with EN 474-5.
Legend
A: Reach from swing centre
B: Bucket hook height
(1) Position of lifting point
(2) Arm length
(3) Boom length
(4) Hydraulic pressure: 34.8 MPa
Working conditions
• Bucket: 400 kg
• Width shoe: 500 mm
• With fully extended bucket cylinder.
• On a compact horizontal level ground.
• If object handling is performed with other tool installed, the weight difference of the tool shall be deducted
from value of this table.
