MAINTENANCE PROCEDURE
WHEN REQUIRED
METHOD FOR CHECKING, CLEANING AND REPLACING AIR CLEANER
• If inspection, cleaning, or maintenance is performed while the engine is running, dust enters into
the engine and damages it. Be sure to stop the engine before performing these works.
• When using compressed air, there is a danger that dirt may scatter and cause personal injury. Wear
the protective equipment such as protective eyeglasses and dust mask.
• When working on a high place or in the place where the foothold is poor, be careful not to fall be-
cause of the reaction when pulling out the outer element.
NOTICE
If the air cleaner is not cleaned or maintained sufficiently, the mass air flow sensor which is installed to
the air cleaner does not function correctly, and it may cause a decrease in the engine performance.
METHOD FOR CHECKING AIR CLEANER
The air cleaner clogging caution lamp informs when the air cleaner element should be checked.
Check that air cleaner clogging caution lamp (1) on the ma-
chine monitor is lit.
If the air cleaner clogging caution lamp (1) lights up, clean the
air cleaner element.
METHOD FOR CLEANING AIR CLEANER OUTER ELEMENT
NOTICE
• Never remove the inner element. If it is removed, dirt will enter and can cause an engine trouble.
• Do not use a screwdriver or other tool.
• When cleaning the element, do not hit it or hit anything with the element.
• Before and after cleaning the element, do not leave or keep it under direct sunlight.
Clean the outer element in the following procedure.
1.
Open the battery inspection cover on the left side of the
machine, remove the hooks (2) (3 places), and remove the
cover (3).
To Next Page
