5-2
WEN
AM00
111
SPEC
IFICA
TIONS
SPEC
IFICA
TIONS
SP
EC
IFICA
TION
S
SP
ECI
FICA
TIONS
:
PC
138US
-
11
Item
Un
it
PC138US-
11
Machine weigh
t
kg
13800
Bucket capac
ity
m
3
0.50
Engine mode
l
-
Komatsu SAA4D95LE-7 diesel en
gine
Rated h
orsep
ower
SAE
J19
95
(g
ro
ss)
kW /
r
pm
72.
6/205
0
IS
O
924
9/SAE
J1349 (ne
t)
72.
5/205
0
A
Overall length (standard spe
cificat
ion)
mm
7280
A'
Overall length (blade spe
cifi
cat
ion)
mm
7970
B
Overall heig
ht
mm
2950
C
Overall widt
h
mm
2490
C'
Overall widt
h
mm
2490
D
Shoe widt
h
mm
500
E
Tail
swing
rad
ius
mm
1480
F
Overall length
of
t
ra
ck
mm
3610
G
Distance between
tumbl
er c
enter
s
mm
2880
H
Cab he
ight
mm
2815
Minimum ground cle
ar
anc
e
mm
395
Travel speed (
Lo/H
i)
km
/h
2.9/5.1
Continuous swing
speed
r
pm
11.0
395
397
