MACHINE OPERATIONS AND CONTROLS
LOCK
Position to be locked
Always lock the following places.
(1) Fuel tank filler cap
(2) Hydraulic tank oil filler cap
(3) Operator's cab door
(4) Toolbox and grease pump storage cover
(5) Left front cover of the machine
(6) Battery inspection cover
(7) Engine hood
(8) Machine right front cover
(9) Fuel filter inspection cover
REMARK
Use the starting switch key to lock and unlock all these places.
METHOD FOR OPENING AND CLOSING CAP WITH LOCK
PROCEDURE FOR OPENING CAP WITH LOCK
1.
Insert the key into the key slot.
2.
Turn the key clockwise, align the matching marks (1) of the
key groove and the cap, then open the cap.
Position (A): OPEN
Position (B): CLOSE (LOCK)
PROCEDURE FOR CLOSING CAP WITH LOCK
1.
Screw in the cap until it becomes tight, then insert the key into the key slot.
2.
Turn the starting switch key to CLOSE position (B), then remove the key.
