Kubota LX2610 User Manual

Mid PTO speed
LX2610/LX3310
Engine speed 2500 rpm
PTO speed 2500 rpm
Rear PTO speed
LX2610/LX3310
Engine speed 2398 rpm
Shaft 6-spline
PTO speed 540 rpm
2. PTO clutch lever [LX2610/LX3310]
IMPORTANT :
• T
o avoid shock loads to the PTO, reduce engine
throttle from high idle to low idle by pushing up
on engine throttle when engaging the PTO, then
open the throttle to the recommended engine
rpm.
• To avoid damage to PTO clutch and implement,
shift the PTO clutch lever slowly, when
engaging the PTO clutch. Do not keep the PTO
clutch lever half way.
• To avoid damage of transmission, when PTO
select lever is not smoothly shifted, slightly
shift PTO clutch lever.
• To avoid damage of transmission, do not shift
PTO select lever until the PTO has stopped
completely.
1. The
PTO clutch lever engages or disengages the
PTO clutch which gives the PTO independent
control.
2. Shift the lever to “ON” to engage the PTO clutch.
Shift the lever to “OFF” to disengage the PTO
clutch.
ROPS model
(1) PTO clutch lever
“ON” “ENGAGE”
“OFF” “DISENGAGE”
CAB model
(1) PTO clutch lever
“ON” “ENGAGE”
“OFF” “DISENGAGE”
NOTE :
• T
ractor engine will not start if the PTO clutch
lever is in the engaged “ON” position.
• When you stand up from the seat with the
PTO clutch lever in the “ON” position, the
engine will stop regardless of the position of
the PTO select lever.
This is because the tractor is equipped with
operator presence control (OPC) system.
3. PTO clutch lever [LX2610SU]
IMPORTANT :
• T
o avoid shock loads to the PTO, reduce engine
throttle from high idle to low idle by pushing up
on engine throttle when engaging the PTO, then
reengage the engine to high idle.
• To avoid damage to PTO clutch and implement,
shift the PTO clutch lever slowly, when
engaging the PTO clutch. Do not keep the PTO
clutch lever half way.
1. The tractor has a 540 rpm speed position.
PTO OPERATION PTO
LX2610,LX3310
75
