1.1 Front jack point
WARNING
T
o avoid personal injury or death:
• Before jacking up the tractor, park it on a firm
and level ground and chock the rear wheels.
• Fix the front axle to keep it from pivoting.
• Select jacks that withstand the machine weight
and set them up as follows.
(1) Jack point
2. Rear wheels
Rear tread width can not be adjusted.
IMPORT
ANT :
• When re-fitting or adjusting a wheel, tighten the
bolts to the following torques then recheck after
driving the tractor 200 m (200 yard) and 10
times of shuttle movement by 5 m (5 yards), and
thereafter according to service interval.
(See MAINTENANCE on page 103.)
2.1 Rear jack point
WARNING
To avoid personal injury or death:
• Before jacking up the tractor, park it on a firm
and level ground and chock the front wheels.
• Fix the front axle to keep it from pivoting.
• Select a jack that withstands the machine
weight and set it up as follows.
(1) Jack point
WHEEL ADJUSTMENT TIRES, WHEELS AND BALLAST
