Kubota R540 User Manual

SPECIFICATIONS
SPECIFICATION TABLE
Model R540
Type CANOPY CAB
*1
Operating weight kg 4355 4520
Bucket capacity m
3
0.68
Engine
Manufacturer KUBOTA
Model Water-cooled V2607-CR-E5-WL
Horse power
SAE J1995
kW/rpm
(HP/rpm)
38.0 / 2400
(51.0 / 2400)
SAE J1349
kW/rpm
(HP/rpm)
35.7 / 2400
(47.9 / 2400)
Number of cylinders 4
Displacement cc 2615
Starter V/kW 12 / 2
Battery V/Ah 12 / 95
Dimensions
Overall length mm 5395
Overall width (without bucket) mm 1680
Overall height mm 2460 2480
Min. ground clearance mm 330
Wheel base mm 2000
Tread mm 1355
Angle of articulation Deg 40 each
Angle of oscillation Deg 8 each
Loader clearance circle mm 4146
Bucket
Hinge pin height mm 3230
Dump height (w/cutting edge) mm 2525
Reach fully raised (w/cutting edge) mm 730
Tipping load
Straight (ISO 14397-1) kg 3280 3440
Full turn (ISO 14397-1) kg 2880 3020
Rated operating capacity (ISO 14397-1) kg 1440 1510
Lifting capacity at ground level
kgf
(kN)
3069
(30.1)
Breakout force (ISO 14397-2)
kgf
(kN)
3711
(36.4)
Fork
Tipping load Full turn (ISO 14397-1) kg 2240 2350
Rated operating
capacity
Firm and level ground
(ISO 14397-1)
kg 1790 1880
Rough terrain (ISO
14397-1)
kg 1340 1410
(Continued)
SPECIFICATION TABLE SPECIFICATIONS
R540
27

Kubota R540 Specifications

General

Operating Weight	9171 lbs (4160 kg)
Bucket Capacity	0.8 cu. yd (0.6 m3)
Horsepower	51.0 hp (38.0 kW)
Lift Capacity	1, 950 kg
Lift Capacity at Full Height	1, 950 kg
