Kubota R540 User Manual

(1) Float switch
16. Display selector switch
When pressing the display-selector-switch, the LCD of
the
instrument panel will change from 1 indication
mode to the other.
Change the 3-mode display according to your jobs.
(1) Display selector switch
(2)
LCD
(A) Clock
(B) Tachometer
(C) Hour meter
NOTE :
• W
ith the starter key at the [STOP] position,
press the display-selector-switch of the
instrument panel, and the LCD shows the hour
meter for 15 seconds.
16.1 Setting the clock
1.
Press the user-setting-switch.
2. Select the clock-setting-mode by pressing the
display-selector-switch.
The clock-setting-request-indicator
on the
instrument panel lights up.
(1) User setting switch
(2) Display selector switch
(3) Clock setting request indica-
tor
NOTE :
• Press
the display-selector-switch for a long
time and the year, month, day, hour, and
minute will be selected in this order.
• While setting the clock, the clock-setting-
request-indicator
on
the instrument panel
is blinking.
3. Set the year.
• Press the user-setting-switch and the numeric
setting will be smaller.
• Press the display-selector-switch and the
numeric setting will be larger.
(1) Year (A) Blinking
User setting switch Display selector switch
2008
2007
2006
2008
2009
2010
CHECKS FOR THE SWITCHES
CHECKS BEFORE STARTING THE MACHINE
R540
39

Kubota R540 Specifications

General

Operating Weight	9171 lbs (4160 kg)
Bucket Capacity	0.8 cu. yd (0.6 m3)
Horsepower	51.0 hp (38.0 kW)
Lift Capacity	1, 950 kg
Lift Capacity at Full Height	1, 950 kg
