(1) Direction switch
(2)
Accelerator pedal
(A) Lighting
(B) Backward
IMPORTANT :
• If
the temperature of hydraulic oil is too low, the
reserve alarm may start sounding when
switching from the backward to the forward
travel. This is not a problem. Just perform a
warm-up run, and then the temperature of
hydraulic oil rises, and the alarm will stop. If the
alarm still keeps sounding, contact your local
dealer.
• Do not decelerate the travel speed suddenly by
direction switch during driving. There is a risk
of being overrun, and the engine may be
damaged. If the overrun occurs, the warning
indicator flashes.
6. Speed control switch
2
speed-control-switches serve to change maximum
speed and low speed.
• Press the right speed-control-switch and the
maximum speed is as follows.
Maximum speed 20 km/h
• Press
the left speed-control-switch, speed is limited
to the following values.
Limited speed 4.6 km/h
(1) Left speed control switch
(2)
Right speed control switch
(A) 4.6 km/h
(B) 20 km/h
IMPORTANT :
• Do
not decelerate the travel speed suddenly by
speed-control-switches during driving. There is
a risk of being overrun, and the engine may be
damaged. If the overrun occurs, the warning
indicator flashes.
7. Precautions for turning the
machine
WARNING
T
o avoid personal injury or death:
• Do not turn sharply at high speeds. It is
dangerous. In the worst possible case, the
machine may turn over.
• The steering wheel for this machine will not
return of itself to the straight ahead position
after turning. Be sure to return the steering
wheel to the straight ahead position.
• Steering lose will result if the engine is stopped
during travel.
Do not stop the engine during travel.
To steer the machine to either side, turn the steering
wheel in the intended direction.
• The front and rear frames of this machine bend at
the center pin (the pin connecting the 2 frames) so
OPERATION OF THE MACHINE TRAVELING WITH MACHINE
