(1) Inching and brake pedal (A) Press fully
(B) Release pedal
2. Using the inching and brake pedal
according to the job
WARNING
T
o avoid personal injury or death:
• When traveling with a fully-loaded bucket, do
not press the inching-and-brake-pedal all the
way. The machine will brake abruptly and cause
dangerous loss of balance that may cause an
accident.
(1) Inching and brake pedal (2) Accelerator pedal
Loading
1. Press
the inching-and-brake-pedal slightly while
pressing the accelerator pedal to approach an
object slowly.
You can also perform slow approach of inching-
and-brake-pedal by regulating accelerator-pedal
operation.
You can operate the bucket at the maximum engine
rpm when the inching-and-brake-pedal is used to
approach slowly. Bucket-operation-speed is thus
maintained.
2. Press the inching-and-brake-pedal slightly to allow
the machine to approach to the desired stop
position.
3. Then
press the inching-and-brake-pedal all the way
to stop the machine completely.
(1) Inching and brake pedal (A) Press slightly
(B)
Press all the way
Refilling
1. Press
the inching-and-brake-pedal slightly to
approach the desired stop position.
2. Then press the inching-and-brake-pedal all the way
to stop the machine at the exact position.
• The traveling speed automatically decreases to
prevent the engine stalling as the external load
increases.
• During traveling with bucket operation, the
traveling speed abruptly increases at the time of
dumping operation since the external load
changes at that time.
3. Use the inching-and-brake-pedal and concentrate
the power to the attachment operation near holes or
slopes.
OPERATION OF THE MACHINE HOW TO USE THE INCHING AND BRAKE PEDAL
82
R540

Kubota R540 Specifications

General

Operating Weight	9171 lbs (4160 kg)
Bucket Capacity	0.8 cu. yd (0.6 m3)
Horsepower	51.0 hp (38.0 kW)
Lift Capacity	1, 950 kg
Lift Capacity at Full Height	1, 950 kg
