Kubota R540 User Manual

OPERATING THE LIFT ARM
To lower the lift arms
1.
Push the control lever forward.
2. Push the control lever to (B), fix the float position.
(1) Control lever (A) Lower
(B)
Float
To fix the float position, press the float switch.
(1) Float switch
To raise the lift arms
1.
Pull the control lever backward.
(1) Control lever (A) Raise
NOTE :
• T
o stop the operation of lift arm, return the
control lever to the neutral position.
OPERATING THE BUCKET
WARNING
T
o avoid personal injury or death:
• Do not exceed the rated operating capacity of
the unit. If loads exceed the rated operating
capacity, the unit can experience a hydraulic
imbalance when half or medium “lift-arms-
raise” command and “bucket-roll-back” or
“auxiliary-hydraulic-control” command are
input together, which can result in the lift arms
lowering slowly. If you begin to experience the
hydraulic imbalance, either place the lift arms
control in “NEUTRAL” or input full “RAISE”
control, and lift arms lowering will cease.
To roll back
1.
Tilt the control lever to the left.
OPERATION OF THE MACHINE OPERATING THE LIFT ARM
70
R540

Kubota R540 Specifications

General

Operating Weight	9171 lbs (4160 kg)
Bucket Capacity	0.8 cu. yd (0.6 m3)
Horsepower	51.0 hp (38.0 kW)
Lift Capacity	1, 950 kg
Lift Capacity at Full Height	1, 950 kg
