Kubota R540 User Manual

CABIN TYPE MACHINE
1. Front wiper / washer system
[Cabin type only]
Before moving the windscreen wiper, make sure that
the
starter key is at the [RUN] position and then turn on
the front-wiper-system.
Position [0]
The wiper is in neutral.
Position
The wiper moves at regular intervals.
Position
[I]
The wiper moves at normal speed.
• Push the multi-function switch toward the steering
wheel, and the front-washer-system gets starts.
• Do not activate the front-washer-system if the tank
for the cleaning fluid is empty. The pump can be
damaged.
• Do not activate the front-wiper-system if the window
is dry. In this case, make sure that cleaning fluid is
applied to the window pane before activating the
wiper.
• In frosty conditions, make sure that the wiper blade
is not frozen to the glass before switching-on. The
motor can be damaged if the wiper system is used
under such conditions.
(1) Multi function switch (A)
Position
(B) Position 0
(C)
Position I
(D) Front washer system
2. Rear wiper / washer system
[Cabin type only]
1. T
o move the rear wiper, turn on the rear wiper /
washer system for the rear wiper when the starter
key in position [RUN].
2. A further push on the rear wiper / washer switch will
activate the washer system.
Even when the rear-wiper-switch is in position “OFF”,
the rear-washer-system functions if it is pressed.
• Do
not activate the rear-washer-system if the tank
for the cleaning fluid is empty. The pump can be
damaged.
• Do not activate the rear-wiper-system if the window
is dry. In this case, make sure that cleaning fluid is
applied to the window pane before activating the
wiper.
• In frosty conditions, make sure that the wiper blade
is not frozen to the glass before switching-on. The
motor can be damaged if the wiper system is used
under such conditions.
(1) Rear wiper / washer switch
3. Interior lamp [Cabin type only]
1. Press
the interior lamp itself, and the interior lamp
lights up.
2. Press the interior lamp again to turn it off.
(1) Interior lamp
4. Opening and closing the cabin
door [Cabin type only]
1. Unlock the cabin door and pull the door knob.
2. Open the cabin door fully until fixed into place.
CABIN TYPE MACHINE
CHECKS BEFORE STARTING THE MACHINE
R540
47

Kubota R540 Specifications

General

Operating Weight	9171 lbs (4160 kg)
Bucket Capacity	0.8 cu. yd (0.6 m3)
Horsepower	51.0 hp (38.0 kW)
Lift Capacity	1, 950 kg
Lift Capacity at Full Height	1, 950 kg
