Kubota R540 User Manual

3.3 Operating procedure for Inhibit Mode
3.3.1 Regeneration operating procedure for Inhibit Mode
(1) DPF switch
(2) Regeneration indicator
(3) Parked regeneration indicator
(4) Engine warning indicator
(A) Inhibit side
(B) Parked Regeneration side
1. The machine has been set to “Auto Regeneration Mode”
by default.
switch lamp
“ON” “Inhibit Mode” is activated.
“OFF” “Auto Regeneration Mode”
is activated.
2. When
the parked-regeneration-indicator
starts
flashing, follow the procedure in Operating the machine for
Parked Regeneration Mode on page 57.
OPERATION OF THE ENGINE EXHAUST AFTERTREATMENT DEVICES
58
R540

Kubota R540 Specifications

General

Operating Weight	9171 lbs (4160 kg)
Bucket Capacity	0.8 cu. yd (0.6 m3)
Horsepower	51.0 hp (38.0 kW)
Lift Capacity	1, 950 kg
Lift Capacity at Full Height	1, 950 kg
