11. CRANKCASE/CRANKSHAFT
11-3
Bet & Win 2 50
CRANKCASE SEPARATION
Remove the cam chain tensioner slipper bolt.
Remove the cam chain tensioner slipper and
cam chain.
Remove the three right crankcase attaching
bolts.
Remove the left crankcase.
Place the crankcase with the left crankcase
down and remove the right crankcase from the
left crankcase.
Remove the gasket and dowel pins.
Remove the crankshaft from the left
crankcase.
Cam Chain Tensioner Slipper
Cam Chain
Bolt
• Never use a driver to pry the
crankcase mating surfaces apart.
＊
Left Crankcase
Crankshaft
Right Crankcase
Left Crankcase
Left Crankcase
www.PlanDeGraissage.org

KYMCO Bet & Win 250 Specifications

General

Displacement	249.4 cc
Cooling System	Liquid-cooled
Fuel System	Carburetor
Transmission	CVT
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Fuel Capacity	12 liters
Ignition	CDI
Width	770 mm
Height	1, 370 mm
Seat Height	780 mm
Engine Type	4-stroke, single-cylinder
