KYMCO Bet & Win 250 User Manual

7. CYLINDER/PISTON
7-3
Bet & Win 2 50
CYLINDER REMOVAL
Remove the cylinder head. (
!
6-7)
Remove the water hose from the cylinder.
Remove the cam chain guide.
Remove the cylinder.
Remove the cylinder gasket and dowel pins.
Clean any gasket material from the cylinder
surface.
PISTON REMOVAL
Remove the piston pin clip.
Press the piston pin out of the piston.
Water Hose
Dowel Pins
Cam Chain Guide
Gasket
Shop Towel
Cylinder
Piston Pin
Piston
Piston Rings
Place a clean shop towel in the crankcase
to keep the piston pin clip from falling
into the crankcase.
＊
www.PlanDeGraissage.org

KYMCO Bet & Win 250 Specifications

General

Displacement	249.4 cc
Cooling System	Liquid-cooled
Fuel System	Carburetor
Transmission	CVT
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Fuel Capacity	12 liters
Ignition	CDI
Width	770 mm
Height	1, 370 mm
Seat Height	780 mm
Engine Type	4-stroke, single-cylinder
