8. DRIVE AND DRIVEN PULLEYS/
KICK STARTER
8-8
Bet & Win 2 50
Install the drive pulley face, washer and drive
face nut.
Hold the drive pulley with the universal
holder and tighten the drive face nut.
Torque: 88.2_ 98N-m
Universal Holder
CLUTCH/DRIVEN PULLEY
Remove the left crankcase cover. (
!
8-3)
Remove the drive pulley and drive belt. (
!
8-
4)
Hold the clutch outer with the universal
holder and remove the clutch outer nut.
Universal Holder
Remove the clutch outer.
INSPECTION
Inspect the clutch outer for wear or damage.
Measure the clutch outer I.D.
Service Limit: 153.5mm replace if over
Drive Pulley Face
Washer
Special
Special
• Do not get oil or grease on the
drive belt or drive pulley faces.
＊
Clutch Outer
Drive Face Nut
Drive Pulley
Universal Holder
Universal Holder
www.PlanDeGraissage.org

KYMCO Bet & Win 250 Specifications

General

Displacement	249.4 cc
Cooling System	Liquid-cooled
Fuel System	Carburetor
Transmission	CVT
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Fuel Capacity	12 liters
Ignition	CDI
Width	770 mm
Height	1, 370 mm
Seat Height	780 mm
Engine Type	4-stroke, single-cylinder
