KYMCO Bet & Win 250 User Manual

12. COOLING SYSTEM
12-16
Bet & Win 2 50
THERMOSTAT
THERMOSTAT REMOVAL
Remove the seat, met-in box and center
cover.
Drain the coolant.
Disconnect the thermosensor wire from the
thermosensor.
Disconnect the water hose from the
thermostat housing.
Disconnect the air vent tube from the
thermostat housing.
Remove the mounting bolt and the
thermostat housing from the cylinder head.
Remove the two bolts and separate the
thermostat housing halves.
Remove the thermostat from the thermostat
housing.
Thermostat
Thermostat
Bolts
Thermostat
Water Hose
Air Vent Tube
Bolt
www.PlanDeGraissage.org

KYMCO Bet & Win 250 Specifications

General

Displacement	249.4 cc
Cooling System	Liquid-cooled
Fuel System	Carburetor
Transmission	CVT
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Fuel Capacity	12 liters
Ignition	CDI
Width	770 mm
Height	1, 370 mm
Seat Height	780 mm
Engine Type	4-stroke, single-cylinder
