8. DRIVE AND DRIVEN PULLEYS/

KICK STARTER

8-4

Bet & Win 2 50

Install the drive belt air tube and tighten the

tube band screw.

DRIVE PULLEY

REMOVAL

Remove the left crankcase cover.

Hold the drive pulley using an universal

holder and remove the drive face nut and

washer.

Remove the drive pulley face.

Universal Holder

Remove the drive belt from the movable drive

face.

INSPECTION

Check the drive belt for cracks, separation or

abnormal or excessive wear.

Measure the drive belt width.

Service Limit: 22.0mm replace if below

Drive Pulley Face

Universal Holder

• Use specified genuine parts for

replacement.

＊

Movable Drive Face

Drive Belt

Tube Band Screw

Special
