KYMCO Bet & Win 250 User Manual

17. IGNITION SYSTEM
17-3
Bet & Win 2 50
SPARK PLUG
For spark plug inspection and adjustment,
refer to page 3-5.
IGNITION COIL INSPECTION
Remove the seat and met-in box. (
!
2-3)
Remove the ignition coil
IGNITION COIL CONTINUITY TEST
Inspect the continuity of the ignition coil,
primary coil and secondary coil.
Measure the ignition coil resistances at
20℃ .
Primary coil
1.5_ 3.5W
Secondary coil
without plug cap
12_ 16KW
Secondary coil with
plug cap
17_ 21KW
Ignition Coil
AC 110V
This is a general test. Accurate ignition
coil test must be performed with a CDI
tester.
＊
Ignition Coil
Secondary Coil
Primary Coil
Ignition Coil
www.PlanDeGraissage.org

KYMCO Bet & Win 250 Specifications

General

Displacement	249.4 cc
Cooling System	Liquid-cooled
Fuel System	Carburetor
Transmission	CVT
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Fuel Capacity	12 liters
Ignition	CDI
Width	770 mm
Height	1, 370 mm
Seat Height	780 mm
Engine Type	4-stroke, single-cylinder
