KYMCO Bet & Win 250 User Manual

12. COOLING SYSTEM
12-15
Bet & Win 2 50
THERMOSENSOR
THERMOSENSOR REMOVAL
Remove the seat, met-in box and center
cover.
Drain the coolant.
Disconnect the thermosensor wire.
Remove the thermosensor.
THERMOSENSOR INSPECTION
Suspend the thermosensor in a pan of water
over a burner and measure the resistance
through the sensor as the water heats up.
Temperature(
℃ )
50
80
100
120
Resistance(W)
154
52
27
16
THERMOSENSOR INSTALLATION
Apply 3-BOND No. 1212 sealant or
equivalent to the thermosensor threads and
install it into the thermostat housing.
Connect the thermosensor wire.
Fill the radiator with coolant. (
!
3-9)
Install the center cover, met-in box and seat.
(
!
2-3)
Be sure to bleed air from the cooling
system.
＊
Thermosensor
Thermosensor Wire
Thermosensor
Thermosensor Wire
Thermosensor
Thermometer
www.PlanDeGraissage.org

KYMCO Bet & Win 250 Specifications

General

Displacement	249.4 cc
Cooling System	Liquid-cooled
Fuel System	Carburetor
Transmission	CVT
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Fuel Capacity	12 liters
Ignition	CDI
Width	770 mm
Height	1, 370 mm
Seat Height	780 mm
Engine Type	4-stroke, single-cylinder
