12. COOLING SYSTEM
12-9
Bet & Win 2 50
Install the front upper cover.
WATER PUMP
MECHANICAL SEAL (WATER SEAL)
INSPECTION
Inspect the
telltale hole for signs of
mechanical seal coolant leakage.
If the mechanical seal is leaking, remove the
right crankcase cover and replace the
mechanical seal.
WATER PUMP/IMPELLER REMOVAL
Remove the coolant inlet hose and outlet
hose.
Right Crankcase Cover
Telltale Hole
Water Pump
Outlet Hose
Inlet Hose
