SERVICE INFORMATION
GENERAL INSTRUCTIONS
• The water pump must be serviced after removing the engine. Other cooling system service can be
done with the engine installed in the frame.
• The engine must be cool before servicing the cooling system.
When the coolant temperature is over 100℃ , never remove the radiator cap to release the
pressure because the boiling coolant may cause danger.
• Avoid spilling coolant on painted surfaces because the coolant will corrode the painted surfaces.
Wash off any spilled coolant with fresh water as soon as possible.
• After servicing the system, check for leaks with a cooling system tester.
SPECIAL TOOL
Mechanical seal driver
TORQUE VALUES
Water pump impeller 9.8_ 13.7N-m
Water pump cover bolt 7.8_ 11.8N-m
TROUBLESHOOTING
Engine temperature too high Coolant leaks
• Faulty temperature gauge or thermosensor • Faulty pump mechanical (water) seal
• Faulty radiator cap • Deteriorated O-rings
• Faulty thermostat • Damaged or deteriorated water hoses
• Insufficient coolant
• Passages blocked in hoses or water jacket
• Clogged radiator fins
• Passages blocked in radiator
• Faulty water pump
Temperature gauge pointer does not register
the correct coolant temperature
• Faulty temperature gauge or thermosensor
• Faulty thermostat
