KYMCO Bet & Win 250 User Manual

15. REAR BRAKE/REAR FORK/REAR
WHEEL/REAR SHOCK ABSORBER
15-4
Bet & Win 2 50
REAR FORK
REMOVAL
Remove the exhaust muffler. (
!
2-6)
Remove the rear brake caliper. (
!
15-3)
Remove the right rear shock absorber lower
mount bolt.
Remove the rear axle nut and remove the
collar.
Remove the rear fork.
The installation sequence is the reverse of
removal.
Turn the inner race of each bearing with your
finger to see if they turn smoothly and
quietly.
Also check if the outer race fits tightly in the
hub.
Replace the bearings if the races do not turn
smoothly, quietly, or if they fit loosely in the
hub.
REAR WHEEL
REMOVAL
Remove the exhaust muffler. (
!
2-6)
Remove the rear brake caliper. (
!
15-3)
Remove the rear fork.
Remove the rear axle collar.
Remove the rear wheel.
INSPECTION
Measure the rear wheel rim runout.
Service Limits:
Radial: 2.0mm replace if over
Axial: 2.0mm replace if over
Shock Absorber Lower Mount Bolt
Collar
Axle Nut
Rear Axle Collar
Rear Fork
Rear Brake Disk
www.PlanDeGraissage.org

KYMCO Bet & Win 250 Specifications

General

Displacement	249.4 cc
Cooling System	Liquid-cooled
Fuel System	Carburetor
Transmission	CVT
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Fuel Capacity	12 liters
Ignition	CDI
Width	770 mm
Height	1, 370 mm
Seat Height	780 mm
Engine Type	4-stroke, single-cylinder
