Kyocera TASKalfa 4551ci User Manual

9-21
User Authentication and Accounting (User Login, Job Accounting) > User Login
Obtain NW User Property
Set the required information to obtain the network user property from the LDAP server. The user name and E-mail
address obtained with this setting is shown in the user information, the status confirmation screen, and the header of
E-mail.
The table below explains the required information to be registered.
*1 If using Active Directory of Windows, the server name may be the same as the server name entered in the network authentication.
*2 If using Active Directory of Windows, displayName of Attribute may be used as "Name 1".
*3 "Name 2" can be left out. When you assign displayName in "Name 1" and department in "Name 2", and if the value of displayName is
"Mike Smith" and the value of department is "Sales" in Active Directory of Windows, the user name appears as "Mike Smith Sales".
*4 If using Active Directory of Windows, mail of Attribute may be used as E-mail Address.
*5 Appears when the server type is set to "Kerberos" in "Network Authentication".
NOTE
To obtain the network user property from the LDAP server, [Network Authentication] must be selected for the
authentication method in User Login
on page 9-4. Select "On" for "LDAP" in Protocol Settings on page 8-45.
Item Descriptions
Server Name*
1
Enter the LDAP server name or the IP address (up to 64 characters). If a server
name is not entered, user information will be acquired from the server set for
Network Authentication.
Port Set the LDAP port number or use the default port 389.
Name 1*
2
Enter the LDAP Attribute to obtain the user name to be displayed from the
LDAP server (up to 32 characters).
Name 2*
3
Enter the LDAP Attribute to obtain the user name to be displayed from the
LDAP server (up to 32 characters).
E-mail Address*
4
Enter the LDAP Attribute to obtain the E-mail address from the LDAP server
(up to 32 characters).
Authentic at Type*
5
Set the authentication method. Select [Simple] or [SASL]. After changing the
setting, restart the system or turn the power off and then on.
Search Timeout Set the amount of time to wait before time-out in seconds (from 5 to 255
seconds).
LDAP Security Select the type of encryption according to the type of security employed by the
LDAP server. The value is [Off], [SSL/TLS] or [STARTTLS].

Kyocera TASKalfa 4551ci Specifications

General

Duplex printing	Yes
Print technology	Laser
Duplex printing mode	Auto
Time to first page (black, normal)	3.9 s
Time to first page (color, normal)	5.1 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Scan to	E-mail, FTP, USB
Maximum scan area	A3 (297 x 420) mm
Scan speed (color)	160 ppm
Image formats supported	JPG, TIF
Faxing	Color faxing
Fax memory	12 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	No
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL
Paper input type	Cassette, Paper tray
Total input capacity	1150 sheets
Total output capacity	250 sheets
Maximum input capacity	7650 sheets
Total number of input trays	3
Multi-Purpose tray input capacity	150 sheets
Maximum print size	297 x 420 mm
Duplex media weight	60 - 256 g/m²
Paper tray media types	Banner, Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
ISO A-series sizes (A0...A9)	A3, A4
Multi-purpose tray media types	Plain paper
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 300 g/m²
Display	LCD
Product color	Gray
Market positioning	Business
Direct printing	-
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2
Processor model	P1022
Processor family	PMC-Sierra
Internal storage capacity	320 GB
Sound power level (standby)	38.3 dB
Sound pressure level (printing)	50.9 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	1.8 W
Power consumption (average operating)	1030 W
Sustainability certificates	RoHS

Weight and Dimensions

Depth	767 mm
Width	668 mm
Height	747 mm
