OPERATOR’S MANUAL
WRXi-OM-E Rev C 13
Return products requiring only maintenance to your local customer service center.
If you need to return your oscilloscope for any reason, use the original shipping carton. If this is not possible, be
sure to use a rigid carton. The oscilloscope should be packed so that it is surrounded by a minimum of four inches
(10 cm) of shock absorbent material.
Within the warranty period, transportation charges to the factory will be your responsibility. Products under
warranty will be returned to you with transport prepaid by LeCroy. Outside the warranty period, you will have to
provide us with a purchase order number before the work can be done. You will be billed for parts and labor
related to the repair work, as well as for shipping.
You should prepay return shipments. LeCroy cannot accept COD (Cash On Delivery) or Collect Return
shipments. We recommend using air freight.
Technical Support
You can get assistance with installation, calibration, and a full range of software applications from your customer
service center. Visit the LeCroy Web site at http://www.lecroy.com for the center nearest you.
Staying Up-to-Date
To maintain your instrument’s performance within specifications, have us calibrate it at least once a year. LeCroy
offers state-of-the-art performance by continually refining and improving the instrument’s capabilities and
operation. We frequently update both firmware and software during service, free of charge during warranty.
You can also install new purchased software options in your oscilloscope yourself, without having to return it to
the factory. Simply provide us with your instrument serial number and ID, and the version number of instrument
software installed. We will provide you with a unique option key that consists of a code to be entered through the
Utilities' Options dialog to load the software option.
Specifications
Note: Specifications are subject to change without notice.
Vertical System
• Bandwidth @ 50 ohms (-3 dB):
WaveRunner 44Xi
10 mV/div to 1 V/div 400 MHz
5 mV/div to 9.9 m/div 400 MHz
2 mV/div to 4.95 m/div 150 MHz
WaveRunner 64Xi
10 mV/div to 1 V/div 600MHz
5 mV/div to 9.9 m/div 500 MHz
2 mV/div to 4.95 m/div 150 MHz
WaveRunner 62Xi
10 mV/div to 1 V/div 600 MHz
5 mV/div to 9.9 m/div 500 MHz
2 mV/div to 4.95 m/div 150 MHz
WaveRunner 104MXi and
WaveRunner 104Xi
10 mV/div to 1 V/div 1 GHz
5 mV/div to 9.9 m/div 800 MHz
2 mV/div to 4.95 m/div 350 MHz
WaveRunner 204Xi
10 mV/div to 1 V/div 2 GHz
5 mV/div to 9.9 m/div 1 GHz
2 mV/div to 4.95 m/div 350 MHz
