LeCroy WaveRunner XI Series User Manual

WAVERUNNER XI SERIES
76 WRXi-OM-E Rev C
m Grid to Grid
r label for the waveform that you want to move.
Moving Traces fro
You can move traces from grid to grid at the touch of a button.
Moving a Channel or Math Trace
1. Touch the descripto
8. Touch the Next Grid button
Note: If you have more than one waveform displayed on only one grid, a second grid will open automatically
when you select Next Grid.
Zooming Waveforms
The Zoom button appears a button at the bottom of the chas a standard nnel Cx Vertical Adjust setup
can also zoom a memory or
mini-
dialog if you want to create a math function zoom trace of your input waveform. You
math function trace directly without having to create a separate zoom trace. For such traces, a zoom control
dialog is provided at the right of each math trace "Fx" setup dialog for precise control:
ch and drag a rectangle around a portion of the math or memoAlternatively, you can tou
can be done conse
ry trace to zoom it, which
cutively for higher and higher zooms.
Note: If a histogram is applied, the range of the histogram is limited to the portion of the trace that is visible on
screen. That is, if you zoom in on a trace, the histogram will not contain data for that part of the original trace
no longer visible.
The front panel "QuickZoom" button creates multiple zooms, one for each displayed input channel.
rtion of a waveform by touching and dragging a rectangle around any part of
e will size itself to fit the full width of the grid. The degree of magnification,
therefore, will depend on the size of the rectangle that you draw.
At any time, you can also zoom a po
the input waveform. The zoom trac
