OPERATOR’S MANUAL
• Power Consumption: 340 watts (340 VA) max., WaveRunner 62Xi: 290 W (290 VA), depending on
accessories installed (probes, PC port plug-ins, etc.); Standby State: 12 watts
• Physical Dimensions (HWD): 260 mm x 340 mm x 152 mm (10.2 in. x 13.4 in. x 6.0 in.); height
measurement excludes foot pads
• Weight: 6.95 kg (15.3 lbs.)
Warranty and Service
3-year warranty; calibration recommended yearly
Optional service programs include extended warranty, upgrades, and calibration services.
Environmental Characteristics
TEMPERATURE
• Operating: 5 to 40 °C
• Storage (non-operating): -20 to +60 °C
H
UMIDITY
• Operating: Maximum relative humidity 80% for temperatures up to 31 °C decreasing linearly to 50% relative
humidity at 40 °C.
• Storage (non-operating): 5 to 95% RH (non-condensing) as tested per MIL-PRF-28800F
A
LTITUDE
• Operating: Up to 2,000 m
• Storage (non-operating): 12,192 m (40,000 ft)
R
ANDOM VIBRATION
• Operating: 5 Hz to 500 Hz, overall level: 0.31 g
rms
, 15 minutes in each of 3 orthogonal axes
• Non-operating: 5 Hz to 500 Hz, overall level: 2.4 g
rms
, 15 minutes in each of 3 orthogonal axes
S
HOCK
• Functional Shock: 20 g peak, half sine, 11 ms pulse, 3 shocks (positive and negative) in each of 3
orthogonal axes, 18 shocks total
Certifications
CE Compliant, UL and cUL Listed
CE Declaration of Conformity
The oscilloscope meets requirements of EMC Directive 89/336/EEC for Electromagnetic Compatibility and Low
Voltage Directive 73/23/EEC for Product Safety.
EMC Directive:
• EN 61326/A3:2003
• EMC requirements for electrical equipment for measurement, control,
and laboratory use.
Electromagnetic Emissions:
• EN 55011/A2:2002, Radiated and conducted emissions (Class A)*
• EN 61000-3-2/A2:2005 Harmonic Current Emissions (Class A)
• EN 61000-3-3/A2:2005 Voltage Fluctuations and Flickers (Pst = 1)
* To conform to Radiated Emissions standard, use properly shielded cables on all I/O terminals.
WRXi-OM-E Rev C 21
