• Trigger & Interpolator Jitter: </= 3 ps rms (typical)
• Channel-to-Channel Deskew Range: ±9 x time/div setting
• Interpolator Resolution: 1.2 ps
• External Sample Clock (2-channel operation only; Ch 2 only in WaveRunner 62Xi): DC to 600 MHz; 50
ohm (limited BW in 1 Mohm), BNC input, limited to 2 Ch operation (1 Ch in 62Xi), minimum rise time and
amplitude requirements apply at low frequencies.
Threshold
Impedance
(ohms)
Minimum
V
p-p
Minimum Slew Rate
(mV/ns)
TTL 50 3 250
TTL 1 M 3 350
ECL 50 0.2 150
ECL 1 M 0.2 250
0 Cross 50 0.2 150
0 Cross 1 M 0.2 250
• Roll Mode: User selectable; available at lower time/div settings
Acquisition System
Single-shot Sample Rate/Ch: 5 GS/s
WaveRunner
44Xi
WaveRunner
64Xi
WaveRunner
62Xi
WaveRunner
104MXi/Xi
WaveRunner
204Xi
All Channels
5 GS/s 5 GS/s 5 GS/s 5 GS/s 5 GS/s
Interleaved
5 GS/s 10 GS/s 10 GS/s 10 GS/s 10 GS/s
• 2 Channel Max.: 10 GS/s
Maximum Acquisition Points/Ch - 2 Ch/4 Ch
Standard
10M/20M
VL Memory Option
12.5M/25M
• Random Interleaved Sampling (RIS): 200 GS/s
• Trigger Rate: 1,250,000 waveforms per second
Acquisition Modes
• Single-shot: For transient and repetitive signals: 20 ps/div to 1000 s/div
• Sequence: 1000 segments standard
• Sequence Time Stamp Resolution: 1 ns
• Intersegment Time: 800 ns
Acquisition Processing
• Time Resolution (minimum, single-shot): 200 ps (5 GS/s); 100 ps (10 GS/s)
• Averaging: Summed averaging to 1 million sweeps; Continuous averaging to 1 million sweeps
• Enhanced Resolution (ERES): from 8.5 to 11 bits vertical resolution
• Envelope (Extrema): Envelope, floor, roof for up to 1 million sweeps
