OPERATOR’S MANUAL
Configuring the Remote Control Assistant Event Log
bar touch Utilities, then Utilities Setup... in the drop-down menu.
5. To export the contents of the event log to an ASCII text file, touch the Show Remote Control Log button: the
Event Logs popup window appears. Touch inside the DestFilename field and enter a file name, using the
pop-up keyboard. Then touch the Export to Text File button.
1. In the menu
2. Touch the Remote tab.
3. Touch inside the Log Mode field.
4. Select Off, Errors Only, or Full Dialog from the pop-up menu.
Hardcopy
Printing
For print setup, refer to Printing.
Clipboard
This selection prints to the clipboard so you can paste a file into another application (like MS Word, for example).
P
RINTING FROM THE CLIPBOARD
1. In the menu bar touch Utilities, then Utilities Setup... in the drop-down menu.
2. Touch the Hardcopy tab.
3. Under Colors, touch the Use Print Colors checkbox if you want the traces printed on a white background. A
white background saves printer toner.
4. Touch the Grid Area Only checkbox if you do not need to print the dialog area and you only want to show the
waveforms and grids.
5. Touch the Print Now button.
WRXi-OM-E Rev C 161
