5.12 Monitoring
Many monitoring functions that are integrated into the controller can detect errors and
thus protect the device/motor from damage or overload.
Detailed information on the individual monitoring functions can be found in the
following subchapters.
Parameterisable responses
If a monitoring function trips, the response set via the corresponding parameter is carried
out. The following responses can be selected:
"No response": Response/monitoring is deactivated.
"Fault": Change of the operating status by a pulse inhibit of the power output stage.
"Warning": Operating status of the controller remains unchanged. Only a message is
entered into the logbook of the controller.
Related topics:
Device state machine and device statuses
( 86)
Diagnostics & error management
( 380)
Basics on error handling in the controller
( 380)
Error messages of the operating system
( 401)
Monitoring Response Error message
(with activated
monitoring)
Lenze setting Configuration
Device overload monitoring (Ixt) Warning C00604 OC5
Motor load monitoring (I2xt) Warning C00606 OC6
Motor temperature monitoring (PTC) Fault C00585 OH3
Brake resistor monitoring (I2xt) No Reaction C00574 OC12
Motor phase failure monitoring No Reaction C00597 LP1
Motor phse error monitoring before
operation
C02844/2
Mains phase failure monitoring Warning C00565 Su02
Maximum current monitoring No Reaction C00609 OC7
Maximum torque monitoring No Reaction C00608 OT1
Motor speed monitoring Fault - OS2
Encoder open-circuit monitoring Fault C00586 SD3
