8400 StateLine C | Reference manual
About this documentation
Terminology used
24 L Firmware ≤ 11.00 - DMS 8.0 EN - 10/2011
Keypad The keypad is an alternative to the PC for the local operation, parameterisation,
and diagnostics in a simple manner.
• Detailed type designation: X400 keypad
• Order designation: EZAEBK1001
LA Abbreviation for Lenze Application block
Example: "LA_NCtrl" (block for the "Actuating drive speed" application)
Lenze setting This setting is the default factory setting of the device.
LP Abbreviation for Lenze Port block
Example: "LP_CanIn1" (CAN1 port block)
LS Abbreviation for Lenze System block
Example: "LS_DigitalInput" (system block for digital input signals)
Port block Block for implementing the process data transfer via a fieldbus
PSM Abbreviation for permanently excited synchronous motor
QSP Abbreviation for quick stop
SC Abbreviation for Servo Control
Service brake The service brake serves to shutdown rotary or translatory masses in motion in
a controlled manner. The energy to be dissipated in this process is produced in
the form of friction energy. Unlike emergency braking, this process is a regular
and recurring operating mode.
SLPSM Abbreviation for sensorless control of synchronous motors
SLVC Abbreviation for SensorLess Vector Control
Subcode If a code contains several parameters, the individual parameters are stored
under "subcodes".
This Manual uses a slash "/" as a separator between code and subcode
(e.g. "C00118/3").
The term is usually called "subindex".
System block System blocks provide interfaces to basic functions and to the hardware of the
controller in the FB Editor of the »Engineer« (e.g. to the digital inputs).
USB diagnostic adapter The USB diagnostic adapter is used for the operation, parameterisation, and
diagnostics of the controller. Data are exchanged between the PC (USB
connection) and the controller (diagnostic interface on the front) via the
diagnostic adapter.
• Order designation: E94AZCUS
VFCplus Abbreviation for Voltage Frequency Control
Term Meaning
