Firmware ≤ 11.00 - DMS 8.0 EN - 10/2011 L 243
8400 StateLine C | Reference manual
Motor control (MCTRL)
Monitoring
5.12.9 Maximum torque monitoring
This function extension is only available from version 04.00.00!
If the maximum possible torque C00057
is reached at the motor shaft, the response set in
C00608
will be carried out (Lenze setting: "0: No response").
If the activated monitoring is tripped:
The "OT1: Maximum torque reached
" error message is entered into the logbook.
The bMctrlTorqueMax status output of the LS_DeviceMonitor
system block will be set
to TRUE.
5.12.10 Motor speed monitoring
This function extension is available from version 11.00.00!
If the drive reaches the maximally permissible motor speed (C00965
):
The "Fault" error response takes place, i.e. the motor is shut down immediately.
The error message "OS2: Max. motor speed reached
" is entered into the logbook.
Note!
In the Lenze setting (C00608 = "0: No response"), the maximum torque
monitoring is not
activated!
