8400 StateLine C | Reference manual
Commissioning
Commissioning of the "Switch-off positioning" technology application
3.7 Commissioning of the "Switch-off positioning" technology application
System constellation
[3-2] Block diagram for wiring of the commissioning example for the "Switch-off positioning" application
 Note!
Take all the necessary safety precautions before you carry out the following
commissioning steps and switch the device on!
Safety instructions with regard to commissioning
( 48)
X4/RFR Controller enable
X4/DI1 Initiator connection for stop function 1
X4/DI2 Initiator connection for stop function 2
X4/DI3 Quick stop for CW rotation / selection of switch-off position 1
X4/DI4 Quick stop for CCW rotation / selection of switch-off position 2
X6 Diagnostic interface for connecting the USB diagnostic adapter
8400 StateLine
X61
X6
DIAG
AR A1U GA
X3
24I RFR DI1 DI2
X4
DI3 DI4U V W
X6
t [s]
0
1
QSP
Cw
Ccw
-
DI1
DI2
DI1
DI2
v [m/s]
C00039/2
C00012
C00012
C00013
C00039/2
C00013
Cw
Ccw
Cw
Ccw
M
3~
i
0
1
0
0
1
1
