8400 StateLine C | Reference manual
Diagnostics & error management
Logbook
392 L Firmware ≤ 11.00 - DMS 8.0 EN - 10/2011
9.5.4 Exporting logbook entries to a file
How to export the logbook entries to a file:
1. Go to the Logbook dialog box and click the Export... button.
•The Export logbook dialog box is displayed.
2. Specify the folder, file name, and file type for the file.
3. Click the Save button to export the logbook entries to the specified file.
• Hidden logbook entries are not exported, i.e. the filter criteria specified are
accounted for during the export.
• The logbook entries are written to the file in the form of a semicolon separated
list.
Structure of the semicolon separated list
The list includes the following information:
>> more details Show more details:
• Analog value 1, digital values 1 & 2
• More output types of the error numbers (32-bit, internal 32-bit and
internal 16-bit).
•Instead of the >> more details button, the << less details is now displayed
via which the details can be hidden again.
Help Open online help for the logbook.
Resetting an error Acknowledge existing error message if the error cause has been eliminated
and thus the error is not pending anymore.
• After the reset (acknowledgement) of the current error, further errors
may be pending which must also be reset.
Close Close the Logbook dialog box again.
Button Function
1. Cons. no.
2. Active
3. Numerator
4. Type
5. Subject area
6. Error text
7. Time stamp
8. Relative time
9. Error number
10. Source - analog value 1
11. Analog value 1
12. Source - digital value 1
13. Digital value 1
14. Source - digital value 2
15. Digital value 2
