Firmware ≤ 11.00 - DMS 8.0 EN - 10/2011 L 285
8400 StateLine C | Reference manual
I/O terminals
User-defined terminal assignment
Configuration parameters for the inputs of the technology application
The following parameters can be used to change the preconfigured assignment of the
application inputs:
Example
Task:
Starting from the preset technology application "Actuating drive speed" and the
"Terminals 0" control mode, the DI2 digital input is to be used for choosing an alternative
acceleration/deceleration time for the main setpoint instead of for choosing the fixed
setpoint 2/3. To do this, the DI2 digital input is not to be linked to the bJogSpeed2 input but
to the bJogRamp1 input of the application module.
Procedure:
1. Use the keypad to go to the menu level Applications Actuating drive speed (conf.).
This menu level contains all the configuration parameters of the "Actuating drive
speed" technology application".
Configuration parameters ( 315)
2. Navigate to the configuration parameter LA_NCtrl: bJogSpeed2 (C00701/10
) which
represents the logical signal link of the application input bJogSpeed2.
3. Change the setting of C00701/10
:
Change selection "16001: DigIn_bIn2" in selection "0: Not interconnected".
4. Navigate to the configuration parameter LA_NCtrl: bJogRamp1 (C00701/13
) which
represents the logical signal link of the application input bJogRamp1.
5. Change the setting of C00701/13
:
Change selection "0: Not interconnected" in selection "16001: DigIn_bIn2".
Tip!
The example shows that, for each input of the application block, the associated
configuration parameter (C00700/x
or C00701/x) is only allowed to contain one
source that you enter.
Parameter Info
TA "Actuating drive speed": Configuration parameters ( 315)
C00700/1...20
Analog connection list
C00701/1...48
Digital connection list
TA "Switch-off positioning": Configuration parameters ( 343)
C00760/1...16
Analog connection list
C00761/1...47
Digital connection list
