8400 StateLine C | Reference manual
Diagnostics & error management
Error messages of the operating system
408 L Firmware ≤ 11.00 - DMS 8.0 EN - 10/2011
xx.0123.00095 0x175f 5983 FC02: Maximum speed for Fchop No Reaction C00588 0xF000
xx.0123.00099
0x1763 5987 FC03: Field controller limitation No Reaction C00570/4 0xF000
xx.0123.00057
0x1739 5945 Id1: Motor data identification error WarningLocked - 0xF000
xx.0123.00058
0x173a 5946 Id3: CINH motor data identification WarningLocked - 0xF000
xx.0123.00059
0x173b 5947 Id4: Resistance identification error Warning - 0xF000
xx.0123.00074
0x174a 5962 Id5: Pole position identification error Fault C00643/1
xx.0123.00145 0x1791 6033 LP1: Motor phase failure No Reaction C00597 0x3000
xx.0123.00015
0x170f 5903 LU: DC bus undervoltage Trouble C00600/1 0x3100
xx.0123.00016
0x1710 5904 oC1: Power section - short circuit Fault - 0x2000
xx.0123.00017
0x1711 5905 oC2: Power section - earth fault Fault - 0x2000
xx.0119.00050
0x1332 4914 oC5: Ixt overload Warning C00604 0x2000
xx.0123.00105
0x1769 5993 oC6: I2xt motor overload Warning C00606 0x2000
xx.0123.00007
0x1707 5895 oC7: Motor overcurrent Fault - 0x2000
xx.0123.00030
0x171e 5918 oC10: Maximum current reached Fault - 0x2000
xx.0123.00071
0x1747 5959 oC11: Clamp operation active Fault - 0xF000
xx.0123.00065
0x1741 5953 oC12: I2xt brake resistor overload Fault - 0xF000
xx.0123.00090
0x175a 5978 oC13: Maximum current for Fch exceeded Fault - 0xF000
xx.0123.00096
0x1760 5984 oC14: Direct-axis current controller limitation No Reaction C00570/1 0xF000
xx.0123.00097
0x1761 5985 oC15: Cross current controller limitation No Reaction C00570/2 0xF000
xx.0123.00098
0x1762 5986 oC16: Torque controller limitation No Reaction C00570/3 0xF000
xx.0123.00031
0x171f 5919 oC17: Clamp sets pulse inhibit No Reaction C00569/1 0xF000
xx.0119.00001
0x1301 4865 oH1: Heatsink overtemperature Fault - 0x4000
xx.0119.00015
0x130f 4879 oH3: Motor temperature (X106) triggered Fault C00585 0x4000
xx.0119.00000
0x1300 4864 oH4: Heatsink temp. > shutdown temp. -5°C No Reaction C00582 0x4000
xx.0123.00032
0x1720 5920 oS1: Maximum speed limit reached No Reaction C00579 0x8400
xx.0123.00033
0x1721 5921 oS2: Max. motor speed Fault - 0x8400
xx.0123.00001
0x1701 5889 ot1: Max. torque reached No Reaction C00608 0x8300
xx.0123.00093
0x175d 5981 ot2: Speed controller output limited No Reaction C00567 0xF000
xx.0123.00014
0x170e 5902 OU: DC bus overvoltage Trouble - 0x3100
xx.0144.00001
0x2c01 11265 PS01: No memory module Warning - 0x6300
xx.0144.00002
0x2c02 11266 PS02: Invalid par. set Fault - 0x6300
xx.0144.00003
0x2c03 11267 PS03: Invalid device par. set Fault - 0x6300
xx.0144.00004
0x2c04 11268 PS04: Invalid MCI par. set Fault - 0x6300
xx.0144.00007
0x2c07 11271 PS07: Invalid memory module par. set Fault - 0x6300
xx.0144.00008
0x2c08 11272 PS08: Invalid device par. Fault - 0x6300
xx.0144.00009
0x2c09 11273 PS09: Invalid par. format Fault - 0x6300
xx.0144.00010
0x2c0a 11274 PS10: Memory module binding invalid Fault -
xx.0123.00205
0x17cd 6093 Sd3: Feedback system open circuit Fault C00586 0x7300
xx.0123.00200
0x17c8 6088 Sd10: Speed limit for feedback system 12 Fault C00607 0x7300
xx.0111.00002
0x0b02 2818 Su02: One mains phase is missing Warning C00565 0x3000
xx.0111.00003
0x0b03 2819 Su03: Too frequent mains switching Fault - 0x3000
xx.0111.00004
0x0b04 2820 Su04: CU insufficiently supplied Fault - 0x3000
xx.0111.00006
0x0b06 2822 Su06: Mains input overload Fault - 0x3000
xx.0980.00001
- - US01: User error 1 No Reaction C00581/1 0x6200
xx.0981.00002
- - US02: User error 2 No Reaction C00581/2 0x6200
xx.0982.00003
- - US03: User error 3 No Reaction C00581/3 0x6200
xx.0983.00004
- - US04: User error 4 No Reaction C00581/4 0x6200
Error number Error message Response
(Lenze setting)
can be set in CAN Emergency
Error Code
32 bits 16 bits
hex
16 bits
dec
