Firmware ≤ 11.00 - DMS 8.0 EN - 10/2011 L 745
8400 StateLine C | Reference manual
Working with the FB Editor
Reconfiguring the predefined interconnection
5. Select the system block to be inserted in the Search results list field.
6. Press Insert button.
• The dialog box is closed and the selected system block is inserted into the
interconnection.
Context menu for the system block
If you right-click on the header of a system block, a context menu opens via which you can
execute the following functions in addition to the general processing functions (Copy,
Insert, Delete):
Related topics
Deleting objects that are no longer required
( 750)
Changing connector visibilities
( 751)
Arranging objects in the drawing area
( 752)
Creating/deleting connections
( 753)
Command Function
Center Move the visible cutout of the drawing area so that the block is centred.
Connector visibilities... Define visible inputs and outputs of the block.
Changing connector visibilities
( 751)
Online display format... Adapt the display format of the input and output data of the block
individually for online monitoring.
Change online display format
( 739)
Parameter... Open the parameter list/parameterisation dialog for the block.
Help Show online help for the block.
